Recommended for 230VAC Motors outside North America.
Rugged and durable construction.
Grounded aluminum body for safety and short-circuit protection.
Built in the U.S.A.!
Voltage: 230 Volts AC
Maximum steady state current: 15A
Ambient operating temperature: 0° - 110°F
Maximum (Full Inrush Suppression) Duty Cycle: Unlimited Starts per Hour
- The theoretical ramp time of this soft starter is approximately 2 seconds.
- Capacitor start induction motors must be at full speed within 3 seconds of being switched on.
- If your capacitor start induction motor takes longer than 3 seconds to reach full speed, discontinue use of Soft Starter immediately.
- Indoor use only.
- Insert appropriate end of supplied power cord into side of Soft Starter. Plug the other end of power cord into your power receptacle.
- Plug your equipment in to the front outlet of the Soft Starter.
Ramp time is the duration of time required for the Soft Starter output to reach full line voltage.
Ramp time: about 2 seconds
Overall Length: 4.25inches
Overall Width: 3.25 inches
Overall Height: 6.3 inches
